| 產品特色 |
|---|
★ 21.5 inch Industrial Grade Panel, 1920x1080 (FHD) Resolution
★ AHVA Wide Viewing Angle Technology , 178°/178°
★ Intel® 11th Generation Core i Series CPU
★ DDR4 8G RAM (Max. 64G)
★ Narrow Bezel, True Flat Projected Capacitive Touch Screen
★ 7H Hardness Tempered Cover Glass
★ 10 points Multi-touch, Supports NEXTECH Dedicated Stylus
★ Metal Cabinet with Diverse Combine Options
★ Made in Taiwan, 3 Years Warranty
★ Optional High Brightness 1500nits, for Outdoor Environment
★ Optional AG Coating/Antibacterial/Privacy Filter Surface Treatment
| 系統規格 | |
|---|---|
| CPU | Intel® Core i U Series Processor |
| 記憶體 | DDR4 SO-DIMM, Max. Capacity 32G |
| 支援硬碟 | 2 * Intel® GbE LAN Chip (10/100/1000 Mbps, RJ45) |
| 網路功能 |
SATA3.0 7P Connector (With 1 * SATA Power Wafer)x1 M.2 Key-M Slot (PCIe x4/ SATA, Default PCIE 4x, Support PCIe x4 NVMe, 2280) x1 |
| 顯示晶片 |
Intel® UHD Graphics (for i3 CPU) Intel® Iris Xe Graphics (for i3/i5 CPU) HDMI output x1, Max. Resolution 2048x1080 @60Hz DP output x1, Max. Resolution 4096x2304 @60Hz |
| 音效晶片 | Realtek Audio HAD Codec |
| 輸出入介面 |
HDMI x1,DP x1 RJ45 LAN Ports x2 USB 3.0 x6 RS485 x1, RS232 x6 Line-Out + MIC 2in1 3.5mm Jack x1 |
| 操作溫度 | 0~60℃ |
| 儲存溫度 | -20~75℃ |
| 電源輸入 | 12VDC-in |
| 顯示規格 | |
|---|---|
| 面板製程 | Normally Black |
| 對角線尺寸 |
21.5 inch |
| 可視區域 | 476.1x267.8 mm |
| 解析度 | 1920x1080 (FHD) |
| 支援色彩 | 16.7M Colors |
| 亮度 (nits) | 500 / (Optional) 1500 nits |
| 對比 | 1000:1 |
| 螢幕比例 | 16:9 |
| 像素大小 | 0.24795x0.24795 mm |
| 反應時間 | 14 msec. |
| 可視角度 (左/右,上/下) | 178°/178° |
| 背光結構 | LED (white LED) |
| 背光壽命 | >30000 hours |
| 操作溫度 | 0°~50°C |
| 儲存溫度 | -20°~60°C |
| 觸控規格 | |
|---|---|
| 觸控面板 | Projected Capacitive |
| 觸控點數 | 10 points |
| 保護玻璃厚度 | 2.9±0.2mm |
| 保護玻璃表面硬度 | 7H |
| 準確度 | 99.00% |
| 透光率 | ≧87% |
| 防護等級 | IK07 |
| 配件加購 | |
|---|---|
側邊支架 |
前嵌套件 |
被動式觸控筆 |
壁掛架 |
IP65 防水前框 |
桌上型腳座 B |
桌上型腳座 Z |
 |
