| Features |
|---|
★ 19 inch Industrial Grade Panel, 1280x1024 Resolution
★ Wide Operating Temperature Range -30~85℃
★ Metal Cabinet with Diverse Combine Options
★ Made in Taiwan, 3 Years Warranty, Designed for Harsh Environments
★ Resistive/Capacitive Touch Options
★ Optional Video Input (VGA/DVI/HDMI/DP)
★ Optional Software Remote Control by RS232 or DDC/CI
★ Optional 9~36VDC Power Input
★ Optional High Brightness 1500nits, for Outdoor Environment
★ Optional Auto Dimming Function (with Light Sensor)
★ Optional AG Coating/Antibacterial/Privacy Filter Surface Treatment
| Display Specification | |
|---|---|
| Panel Process | TN Mode, Normally White |
| Display Size | 19 inch |
| Visible Area | 376.3x301.1 mm |
| Resolution | 1280x1024 |
| Display Ratio | 4:3 |
| Color Depth | 16.7M Colors |
| Brightness (nits) | 1000 / 1500 nits (Optional) |
| Contrast Ratio | 800:1 |
| Pixel Pitch | 0.294x0.294 mm |
| Response Time | 10 msec. |
| Viewing Angle | 170°/160° |
| Backlight | LED (white LED) |
| Backlight Lifetime | >50000 HRS |
| Operating Temp. | -30°~85°C |
| Storage Temp. | -30~85℃ |
| Touch Specification | |
|---|---|
| Touch Technology | Resistive Touch |
| Allowed Touch Points |
Single point |
| Interface | USB/RS232 |
| Hardness | ≧3H |
| Precision | 98.50% |
| Transparency | 80%±5% |
| Surface Treatment | Anti glare<15% |
| Optional Accessories | |
|---|---|
Open Frame Brackets |
Panel Mount Kits |
Desktop Stand B type |
Desktop Stand Z type |
Wall Mount Bracket |
Passive Stylus |
