| Features |
|---|
★ 15.6 inch Industrial Grande Panel, 1920x1080 (FHD) Resolution
★ AHVA Wide Viewing Angle Technology (178°/178°)
★ Wide Operating Temperature Range -20~70℃
★ Made in Taiwan, 3 Years Warranty, Designed for Harsh Environments
★ Resistive/Capacitive Touch Options
★ Optional Video Input (VGA/HDMI/DP)
★ Optional Software Remote Control by RS232 or DDC/CI
★ Optional 9~36VDC Power Input
★ Optional High Brightness 1500nits, for Outdoor Environment
★ Optional Auto Dimming Function (with Light Sensor)
★ Optional AG Coating/Antibacterial/Privacy Filter Surface Treatment
| Display Specification | |
|---|---|
| Panel Process | AHVA, Normally Black |
| Display Size | 15.6 inch |
| Visible Area | 344.2x193.6 mm |
| Resolution | 1920x1080 (FHD) |
| Display Ratio | 16:9 |
| Color Depth | 16.7M Colors |
| Brightness (nits) | 500 / (Optional) 1000 / (Optional) 1500 nits |
| Contrast Ratio | 1000:1 |
| Pixel Pitch | 0.17925x0.17925 mm |
| Response Time | 25 msec. |
| Viewing Angle | 178°/178° |
| Backlight | LED (white LED) |
| Backlight Lifetime | >50000 HRS |
| Operating Temp. | -20°~70°C |
| Storage Temp. | -20°~70°C |
| Optional Accessories | |
|---|---|
Open Frame Brackets |
Panel Mount Kits |
Desktop Stand B type |
Desktop Stand L type |
Wall Mount Bracket |
 |
